FenceTrac double gate kits are available in two standard widths: 8 feet and 12 feet. Both configurations use aluminum gate frames that accept the same infill boards as the adjacent fence panels. Each double gate kit includes stainless steel hinges, a lockable latch, and a commercial drop rod for securing the stationary gate leaf. Double gates are available in the same heights as the fence system: 4-foot, 6-foot, and 8-foot configurations.
The Short Answer
FenceTrac manufactures two standard double gate widths.
| Gate Type | Total Opening Width | Frame Material | Hardware Included |
|---|---|---|---|
| Double gate (standard) | 8 feet | Aluminum | Stainless steel hinges, lockable latch, commercial drop rod |
| Double gate (wide) | 12 feet | Aluminum | Stainless steel hinges, lockable latch, commercial drop rod |
Both sizes accept the same infill as the fence panels: LuxeCore aluminum-core composite, UltraBlend PVC, aluminum boards, cedar, or any rigid infill up to 1 inch thick.
When to Choose an 8-Foot Double Gate
The 8-foot double gate is the standard choice for residential driveways, RV access, and backyard openings where a single gate is too narrow. Each leaf swings independently at approximately 4 feet wide, providing a full 8-foot clear opening when both leaves are open.
Common residential applications include driveway entries for vehicles, backyard access for trailers and boats, and side yard openings for lawn equipment or construction access during home projects.
The 8-foot width also works well for dumpster and utility enclosures where the opening needs to accommodate a front-load waste container or a service vehicle approach.
When to Choose a 12-Foot Double Gate
The 12-foot double gate provides a wider opening for commercial properties, large equipment access, and applications where vehicles or machinery need additional clearance.
Each leaf swings at approximately 6 feet wide, creating a 12-foot clear opening. This width accommodates box trucks, large trailers, farm equipment, and commercial service vehicles that cannot fit through an 8-foot opening.
Commercial properties, industrial sites, and agricultural operations are the most common applications for the 12-foot double gate. It provides vehicle-grade access while maintaining the same privacy, security, and design consistency as the rest of the fence line.
The Commercial Drop Rod
Every FenceTrac double gate kit ships with a commercial drop rod. The drop rod secures the stationary leaf (the gate leaf that stays closed during normal use) to the ground, preventing it from swinging open under wind pressure or accidental contact.
During everyday use, one leaf stays pinned with the drop rod while the other leaf operates as the active swing gate. When full-width access is needed, the drop rod lifts out of the ground receiver and both leaves swing open.
The drop rod is a surface-mounted, galvanized steel component that pins into a ground-mounted receiver. It adds structural stability to the gate assembly and keeps the stationary leaf aligned with the fence line.
Infill and Color Matching
Like the single gate kits, FenceTrac double gates accept the same infill boards used in the fence panels. The gate frame is powder-coated to match the fence frame color in Black, Bronze, White, or Silver.
This means the double gate blends into the fence line rather than standing out as a separate element. From either side of the fence, the gate presents the same infill material, color, and texture as the adjacent panels.
Watch: FenceTrac Gate Kit Assembly
This video walks through the full assembly process for a FenceTrac gate kit, from frame layout to infill installation.
Adjusting a Standard Double Gate to a Narrower Width
FenceTrac standard double gate kits can be adjusted to any width narrower than the kit size. The top rail and bottom rail on each gate leaf are field-cut to the desired width, and the leaves are reassembled at the new dimensions.
An 8-foot double gate kit can become a 7-foot opening, or a 12-foot kit can be trimmed to 10 feet. The installer measures the opening, divides the total width between the two leaves, cuts the horizontal rails on each leaf to fit, and reassembles with the same hardware and infill.
This is the fastest way to fit a standard gate kit to a non-standard opening without placing a custom order. The aluminum gate frame cuts cleanly with standard metal-cutting tools, and both leaves retain the same structural integrity and infill compatibility as full-width kits.
Custom and Commercial Gate Options
For openings wider than 12 feet or projects that need non-standard heights or heavy-duty configurations, FenceTrac builds custom steel welded gates to specific dimensions.
For commercial and industrial properties that need rolling, sliding, or cantilever gate designs, FenceTrac manufactures these as custom builds. Cantilever and sliding gates are common for openings wider than 12 feet or where swing clearance is limited by the site layout. These custom gates use heavy-duty posts and track systems engineered for the specific application.
Properties exploring automated gate openers can have mounting brackets incorporated during the custom gate build or field-installed on standard gate kits by the installer.
Related Questions
What is the standard width for a single FenceTrac gate? FenceTrac single gates are available in 4-foot and 6-foot standard widths, with stainless steel hinges and a lockable latch included.
Can I add an automated opener to a FenceTrac gate? Yes. FenceTrac does not supply the opener, but mounting brackets can be incorporated on custom gates or field-installed on standard gate kits by the installer.
See Also
FenceTrac enclosures for gate configurations in dumpster, utility, and equipment screening applications. How to build an extremely strong privacy fence for engineering details on the FenceTrac frame and post system.
